This is a new Harting 5-port RJ45 Ha-VIS eCon 3050GBT-A-P Unmanaged Ethernet Switch with part number 24034050020. The Ha-VIS eCon 3000 Full Gigabit family of unmanaged Ethernet switches is equipped with up to 5 gigabit Ethernet ports and allows for cost-efficient and quick expansion and/or reconstruction of network infrastructures with high bandwidth requirements.

Features:

• Switches work as power sourcing equipment (PSE) and can supply up to 4 terminal devices via PoE (34.2 Watts per port)
• RJ45 transfer length of 100m via twisted pair Cat. 5 with a 10/100 Mbit/s transfer rate
• SC Duplex ports provide a transfer speed of 100 Mbits/s with a range of 2KM (Multimode) and 15KM (Single Mode)
• Energy-efficient Ethernet greatly reduces consumption
• Non-Blocking full Ethernet Switching architecture, in accordance with IEEE 802.3
• Auto-Negotiation, auto-polarity and auto-MDI(X) provide the user with a plug & play solution
• Supports extra-long Ethernet frames (Jumbo frames)
• Fibre-optic (SC Duplex) configuration options available
• Can support both 24/48V DC power supplies
• Commercial temperature range of 0°C to 55°C, industrial temperature range of -40°C to 70°C
• Reverse polarity & surge protection
• Anodised Aluminium housing with powder-coated steel sheet
• Optimised DIN rail bracket for a secure installation

Specifications:

• RJ45 Ports: 5
• Transmission Speed: 10 Mbit/s, 100 Mbit/s, 1000 Mbit/s
• Transmission Length: 100m
• Mounting: DIN Rail
• Nominal Supply Voltage: 54V dc
• Dimensions: 25 x 107.5 x 142mm
• Maximum Operating Temperature: 70°C
• Maximum Supply Voltage: 60V dc
• Minimum Operating Temperature: -40°C
• Minimum Supply Voltage: 9V dc
