Features

• Waterproof, conforms to IP68
• Strong Zinc Alloy Electroplated anti-vandal case
• Full programming from the keypad
• 2000 uses, supports Card, PIN, Card PIN
• Can be used as a stand alone keypad
• Backlight keys
• Wiegand 26 input for connection to external reader
• Wiegand 26 output for connection to a controller
• Adjustable Door Output time, Alarm time, Door Open time
• Very low power consumption (30mA)
• Fast operating speed, <20ms with 2000 users
• Lock output current short circuit protection
• Easy to install and program
• Built in light dependent resistor (LDR) for anti tamper
• Built in buzzer
• Red, Yellow and Green LEDS display the working status

Specifications

1. Input Voltage AC/DC 12V
2. Idle Current<25mA
3. Lock output load<1A
4. Alarm output load<1A
5. Ring bell load<1A
6. Card reading distance 40mm Max
7. Card Frequency: 125KHz for EM and HID
8. 13.56MHz for Mifare
9. Card transmission format 26-37 bit wiegand
10. Keypad transmission format:4bit,8bit and Virtual card number
11. Operating Temperature:-45°C～55° C
12. Operating Humidity:0%～95%
